M32 GCode file not found
Hi,
After running the test project without issue I've been unable to start any of the actual projects I got the machine for.
It turns out that any gcode I generate (MESHCAM and Carbide Create so far) give out a file not found when started or simulated (giving out M37 instead obvs).
Once uploaded to the workbee's SD card the files can be loaded into the 3d GCode viewer module, edited or renamed. Which tells me the machine can find the files just fine. In the viewer however, only the travels are displayed without any of the operations, unlike what happens if I load the first project.
CAMotics as been used to simulate the files outside their generator and read all of them flawlessly, so I suppose the issue must come from the workbee itself.
I have noticed that the first project will give an object height in the job list while mine won't, so I suspect a compatibility issue somewhere in there.
Is there any specific requirements for the workbee's gcode formatting or otherwise? The files generated by both cam software are .nc and I've already tried renaming them to .gcode like the first project file, without any effect.
I will copy the Diagnostics output below and link the last gcode file I tried via google drive.
11/24/2024, 1:04:55 AM M122 === Diagnostics === RepRapFirmware for Duet 2 WiFi/Ethernet version 3.3 (2021-06-15 21:44:54) running on Duet WiFi 1.02 or later Board ID: 0JD2M-9F8TA-GJ4TJ-6JKFD-3S86Q-1RVA6 Used output buffers: 3 of 24 (20 max) === RTOS === Static ram: 23876 Dynamic ram: 74584 of which 332 recycled Never used RAM 12768, free system stack 124 words Tasks: NETWORK(ready,89.5%,233) HEAT(delaying,0.0%,386) Move(notifyWait,0.5%,313) MAIN(running,9.8%,514) IDLE(ready,0.2%,29), total 100.0% Owned mutexes: WiFi(NETWORK) === Platform === Last reset 06:02:32 ago, cause: power up Last software reset at 2024-11-10 15:48, reason: User, GCodes spinning, available RAM 13336, slot 0 Software reset code 0x0003 HFSR 0x00000000 CFSR 0x00000000 ICSR 0x0041f000 BFAR 0xe000ed38 SP 0x00000000 Task MAIN Freestk 0 n/a Error status: 0x00 Step timer max interval 0 MCU temperature: min 20.0, current 28.1, max 28.4 Supply voltage: min 23.3, current 23.9, max 24.6, under voltage events: 0, over voltage events: 0, power good: yes Heap OK, handles allocated/used 99/1, heap memory allocated/used/recyclable 2048/40/16, gc cycles 0 Driver 0: position 350895, standstill, SG min/max 0/477 Driver 1: position 150326, standstill, SG min/max 0/451 Driver 2: position 15320, standstill, SG min/max 8/460 Driver 3: position 150326, standstill, SG min/max 0/444 Driver 4: position 0, standstill, SG min/max not available Driver 5: position 0 Driver 6: position 0 Driver 7: position 0 Driver 8: position 0 Driver 9: position 0 Driver 10: position 0 Driver 11: position 0 Date/time: 2024-11-24 01:04:53 Cache data hit count 4294967295 Slowest loop: 188.20ms; fastest: 0.11ms I2C nak errors 0, send timeouts 0, receive timeouts 0, finishTimeouts 0, resets 0 === Storage === Free file entries: 10 SD card 0 detected, interface speed: 20.0MBytes/sec SD card longest read time 4.3ms, write time 38.7ms, max retries 0 === Move === DMs created 83, maxWait 7282601ms, bed compensation in use: none, comp offset 0.000 === MainDDARing === Scheduled moves 1521, completed moves 1521, hiccups 0, stepErrors 0, LaErrors 0, Underruns [0, 0, 36], CDDA state -1 === AuxDDARing === Scheduled moves 0, completed moves 0, hiccups 0, stepErrors 0, LaErrors 0, Underruns [0, 0, 0], CDDA state -1 === Heat === Bed heaters = -1 -1 -1 -1, chamberHeaters = -1 -1 -1 -1 === GCodes === Segments left: 0 Movement lock held by null HTTP is idle in state(s) 0 Telnet is idle in state(s) 0 File is idle in state(s) 0 USB is idle in state(s) 0 Aux is idle in state(s) 0 Trigger is idle in state(s) 0 Queue is idle in state(s) 0 LCD is idle in state(s) 0 Daemon is idle in state(s) 0 Autopause is idle in state(s) 0 Code queue is empty. === Network === Slowest loop: 208.79ms; fastest: 0.00ms Responder states: HTTP(0) HTTP(0) HTTP(0) HTTP(0) FTP(0) Telnet(0), 0 sessions HTTP sessions: 1 of 8 - WiFi - Network state is active WiFi module is connected to access point Failed messages: pending 0, notready 0, noresp 0 WiFi firmware version 1.26 WiFi MAC address 4c:75:25:1c:ab:c7 WiFi Vcc 3.33, reset reason Power up WiFi flash size 2097152, free heap 26904 WiFi IP address 192.168.1.101 WiFi signal strength -63dBm, mode 802.11n, reconnections 0, sleep mode modem Clock register 00002002 Socket states: 0 0 0 0 0 0 0 0 11/24/2024, 12:58:55 AM M32 "0:/gcodes/leos mountain basic gcode mm.nc" Error: M32: GCode file "0:/gcodes/leos mountain basic gcode mm.nc" not found 11/24/2024, 12:58:35 AM Connected to workbee.local
